Professional powder coating oven for DIY coating of long workpieces.
Extra Depth: 110 cm internal depth – ideal for exhaust systems, long profiles, and drive shafts.
Efficient Format: Industrial insulation and full performance on any standard 230V power connection.
-
Estimated delivery: 20. May - 24. May
Your payment information is processed securely. We do not store credit card details and have no access to your payment information.
Powder Coating Oven M-Long – 54 x 60 x 110 cm | Professional Curing Oven for Long Components & Profiles
The Long version offers an internal depth of 110 cm, providing the essential space for workpieces that do not fit in standard ovens. This powder coating oven is the ideal solution for long metal profiles, exhaust systems, drive shafts, frame parts, or series of small parts that need to be placed one after another. Despite its impressive usable depth, the oven remains compact in width and operates highly efficiently on a standard 230V socket.
Video: The powder coating oven in the long version – focus on usable depth & capacity.
Maximum Depth – Industrial Insulation
Thanks to the 50 mm thick insulation, the oven maintains an absolutely stable temperature even in the back of the 110 cm deep chamber. This guarantees a consistent curing result over the entire length of the workpiece.
- 110 cm Usable Depth: Perfect for long automotive parts, pipes, rails, and industrial building elements.
- Integrated Rails: The system features rails in the upper section to securely slide workpieces deep into the oven.
- Plug & Play: Full 2.0 kW power – operation on any conventional 230V socket (Schuko).
Technical Details at a Glance
| Specification | Value |
|---|---|
| External Dimensions (H x W x D) | 67 x 75 x 116 cm |
| Internal Dimensions (H x W x D) | 54 x 60 x 110 cm |
| Temperature Range | 0 – 220 °C (continuously adjustable) |
| Heating Time | 20 °C to 180 °C in approx. 25 min. |
| Temperature Control | Analog thermostat controller |
| Power / Voltage | 2.0 kW / 230 V Single Phase (50 Hz) |
| Power Plug | EU (Schuko) |
| Material & Insulation | Galvanized steel; 50 mm insulation |
| Weight | approx. 35 kg |
| Origin / Safety | Manufactured in Lithuania (CE certified) |
Scope of Delivery – Ready for Immediate Use
- 1x Powder Coating Oven M-Long (fully assembled on stable feet)
- 1x Workpiece Holder (matching the deep rail system)
- Operating Manual
Professional Check: Object Temperature: Especially with a depth of 110 cm, monitoring the object temperature at the far end of the workpiece is crucial. We recommend our self-adhesive oven thermometers to ensure the powder is fully cured over the entire length.
Matching Accessories: Use our Pro Powder Coating Gun for application and heat-resistant masking material for perfect edges.
The M-Long version offers industrial volume for long workpieces. No kit – set it up, plug it in, start coating.
